SUNTRONIC PV 7000 PRO

The Suntronic PV 7000 Pro Solar Inverter is a high-capacity 6000W single-phase (1-phase in / 1-phase out) power solution available at Maxell Power, engineered to deliver efficient energy management for modern solar house systems and commercial properties. Designed to optimize daily solar energy usage alongside your best inverter solar setup, it supports up to 7000W maximum PV input power with a maximum DC voltage of 500V DC (360V DC nominal) and an MPP voltage range of 120V–430V DC (110V DC start-up voltage / 27A max input current). Featuring up to 96% maximum DC/AC conversion efficiency, it delivers a rated 26A nominal output current across selectable AC output ranges (220/230/240 VAC).

Operating on a 48V DC nominal battery architecture, the inverter provides up to 120A maximum solar charging current and 120A AC charging current (6000W max charging power) with 93% battery-to-AC efficiency. Built inside a compact, lightweight enclosure (140 x 295 x 468 mm, 12 kg), it supports parallel operation for up to 9 units for large-scale energy expansion. Equipped with versatile communication interfaces (USB, RS232, RS485, WiFi, and Dry-contact), system status tracking and smart monitoring are seamless. Pair this inverter with our MP 5000-ULTRA Lithium Battery or contact our engineering team for technical inquiries.

Frequently Asked Questions

What is the rated continuous output and maximum PV array power for the Suntronic PV 7000 Pro?

The Suntronic PV 7000 Pro features a rated continuous output power of 6000W (6kW) and supports up to 7000W of maximum PV input power.

What is the MPPT voltage range and start-up voltage rating for this model?

It operates with an MPP voltage range between 120V and 430V DC, a maximum DC input voltage of 500V DC, and an initial feeding/start-up voltage of 110V DC.

How many Suntronic PV 7000 Pro units can be connected in parallel?

This model includes built-in parallel capability supporting up to 9 units in parallel to expand power capacity for high-demand applications.

What battery nominal voltage and charging capacities are supported?

It operates on a 48V DC battery system and provides up to 120A maximum solar charge current and 120A maximum AC charge current (6000W total charging power).

What communication ports are integrated for remote system monitoring?

The unit features USB, RS232, RS485, WiFi, and Dry-contact communication ports for local and mobile application monitoring.
