SUNTRONIC PV 6000 PRO

The Suntronic PV 6000 Pro Solar Inverter is a high-capacity 6000VA / 6000W pure sine wave off-grid solar inverter available at Maxell Power, engineered to deliver heavy-duty energy management for residential solar house systems, multi-story homes, and commercial setups. Built with an advanced MPPT solar charge controller supporting up to 6000W maximum PV array input power, it operates efficiently across a wide MPP operating voltage range of 60V–450V DC (500V DC max open-circuit voltage). With a maximum solar input current of 27A and a powerful 120A maximum solar charge current, it maximizes daily solar yield even under low-light or overcast conditions.

Designed for demanding power loads, the Suntronic PV 6000 Pro operates on a 48V DC nominal battery architecture (54V DC floating charge voltage, 63V DC overcharge protection), supporting both Lithium-ion and Lead-Acid energy storage systems with up to 120A total maximum charging current (100A AC charge current). Its intelligent power transfer mechanism ensures zero operational downtime during utility outages—delivering fast transfer times of 10 ms for sensitive personal computers and IT equipment, and 20 ms for standard household appliances. Encased in a compact, durable frame (107 x 322.6 x 420.3 mm, 10.5 kg) with integrated communication interfaces (RS232, RS485, WiFi), remote system performance monitoring is smooth and straightforward. Pair this unit with our high-capacity MP 16000-ULTRA Lithium Battery or connect high-efficiency photovoltaic panels like our Bifacial 525W Half Cut Module. For technical queries and custom system sizing, contact our engineering team.

Frequently Asked Questions

What is the rated continuous output capacity of the Suntronic PV 6000 Pro?

The Suntronic PV 6000 Pro delivers a full 6000W (6000VA) continuous output capacity with a clean pure sine wave output to power heavy household appliances and sensitive electronics safely.

What maximum solar panel capacity can be connected to this inverter?

It supports up to 6000W (6kW) of total PV array input power with an MPPT voltage range between 60V and 450V DC and a maximum open-circuit voltage rating of 500V DC.

What battery voltage and chemistries are compatible with the Suntronic PV 6000 Pro?

This unit operates on a 48V DC nominal battery bank setup and is fully compatible with both Lithium-ion and Lead-Acid battery technologies, supplying up to 120A maximum charging current.

How fast does the inverter switch to battery mode during a power cut?

The inverter features a fast transfer speed of 10 ms when set for Personal Computers and sensitive equipment, and 20 ms for general Home Appliances to protect connected devices against power cuts.

What communication options are available for system monitoring?

The Suntronic PV 6000 Pro comes equipped with RS232, RS485, and WiFi communication interfaces for seamless local and mobile application monitoring.
