VOLTAS HYD-8K-H6 Single Phase Inverter

The Voltas HYD-8K-H6 Single-Phase Hybrid Inverter is built for high performance and dependability, making it perfect for residential and commercial use. This sophisticated inverter supports dual output and enables seamless operation in both on-grid and off-grid configurations. It is a versatile option for those aiming to maximize their energy efficiency.

The inverter is compatible with lead-acid and Li-Ion batteries and operates within a 40-60 V voltage range. It provides a maximum charge and discharge current of 160 A, supporting effective energy management. Its charging strategy includes a 3-stage charging curve and optional external temperature sensors for enhanced performance and battery care.

With a maximum DC input power of 12,000 W and a PV input voltage of 600 V, this inverter is designed to handle a wide range of solar setups. It features Four MPPT trackers, each supporting  1 string, and a startup voltage of 100 V. The inverter delivers a rated AC output power of 8,000 W, with a peak power capability of up to 9,000 W for 10 seconds during off-grid conditions.
